ClampStar® HARDWARE

ClampStar hardware pertains to a variety of items such as: Torque Nuts, Installation Kits, and Mounting Brackets.

All ClampStars are supplied by the factory with pre-installed torque-limiting nuts, or set screws depending on part #, containing an outer section that is designed to snap off when the correct torque level is attained. Additional Torque Nuts are available for purchase and are designed to accommodate different size bolts and different torque ratings.

The Installation Kit contains an eyebolt with a flat washer welded to the eye near the threaded base. When the ClampStar® (CSF, CRU & CSS) units are being installed with hot sticks you need something to grab onto to support the ClampStar flex connector.

The threaded bolt part screws into a tapped hole in the body of the ClampStar and provides a secure means to which a clamp stick or “shotgun stick” can be readily attached. This is removed after installation to be used for the next CSF, CRU or CSS unit installation. This replaces the welded in-place hot stick loop on CSR ClampStar units.

Brackets are used to attach Safe-T-Link tethers to overhead hardware. Several brackets have previously been developed for a variety of overhead hardware configurations and there’s a good chance that one of these brackets will fit your application. Customers are required to provide photos or drawings of their particular hardware so that our factory personnel can determine the best bracket for each application. If a bracket does not presently exist for your specific application, we will design one.

Installation Kits

Torque Nuts

Spline Bits

Back to Catalog

ClampStar Part Number	Conductor Diameter Range			Number of Keepers Per Side	Average Weight		Overall Length
ClampStar Part Number	Conductor Range	Inches	mm	Number of Keepers Per Side	Pounds	Kg	Inches	cm
CSS-1140S-DE-060-X-X	477 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	16/8	TBD	TBD	95	241.3
CSS-1140FT-DE-060-X-X	477 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	20/8	43.8	19.9	99	251.5
CSS-1386S-DE-060-X-X	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	16/10	44.4	20.1	97	246.4
CSS-1386FT-DE-060-X-X	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	20/10	46.2	21.0	101	256.5
CSS-1631S-DE-060-X-X	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	20/12	44	20.0	103	261.6
CSS-1631FT-DE-060-X-X	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	20/12	46.5	21.1	103	261.6
CSS-1912S-DE-066-X	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	20/12	62	28.1	109	276.9
CSS-1912FT-DE-066-X	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	20/12	62	28.1	109	276.9

ClampStar Part Number	Conductor Diameter Range			Number of Keepers Per Side	Average Weight		Overall Length
ClampStar Part Number	Conductor Range	Inches	mm	Number of Keepers Per Side	Pounds	Kg	Inches	cm
Rigid Frame
CSR-0325L-007-P***	#6 AWG – #2 AWG	0.162 – 0.325	4.1 – 8.3	1	1.7	.8	12.2	31.0
CSR-0325-015	#6 AWG – #2 AWG	0.162 – 0.325	4.1 – 8.3	2	3.5	1.6	26.38	67.0
CSR-0609-024	#2 AWG – 266.8 kcmil	0.316 – 0.609	8.0 – 15.5	2	7.7	3.5	43	109.2
CSR-0642L-024***	2/0 AWG – 266.8 kcmil	0.349 – 0.642	8.9 – 16.3	2	7.7	3.5	43	109.2
CSR-0642-024	2/0 AWG – 266.8 kcmil	0.349 – 0.642	8.9 – 16.3	3	14	6.4	52.8	134.1
CSR-0883L-024***	3/0 AWG – 477 kcmil	0.502 – 0.883	12.8 – 22.4	2	13.1	5.9	43.8	111.3
CSR-0883-036	3/0 AWG – 477 kcmil	0.502 – 0.883	12.8 – 22.4	3	19.1	8.7	65.4	166.1
CSR-1108L-024***	336.4 kcmil – 795 kcmil	0.684 – 1.108	17.4 – 28.1	2	14.4	6.5	43.8	111.3
CSR-1108-040	336.4 kcmil – 795 kcmil	0.684 – 1.108	17.4 – 28.1	4	27	12.2	78.8	200.2

ClampStar Part Number	Conductor Diameter Range			Number of Keepers Per Side	Average Weight		Overall Length
ClampStar Part Number	Conductor Range	Inches	mm	Number of Keepers Per Side	Pounds	Kg	Inches	cm
Rigid Frame
CSR-1140S-048	477 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	16	31.9	14.5	92	233.7
CSR-1140FT-048	477 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	20	36.3	16.5	100	254.0
CSR-1386S-060	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	16	33.8	15.3	104	264.2
CSR-1386H-060	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	20	38.7	17.6	112	284.5
CSR-1386FT-060	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	20	38.4	17.4	112	284.5
CSR-1631S-060	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	20	37.9	17.2	112	284.5
CSR-1631H-060	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	26	53	24.04	124	315.0
CSR-1631FT-060	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	20	37.9	17.2	112	284.5
CSR-1912S-060	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	20	50	22.7	112	284.5
CSR-1912H-060	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	26	58.0	26.3	124	315.0
CSR-1912FT-060	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	20	50.3	22.8	112	284.5

ClampStar Part Number	Conductor Diameter Range			Number of Keepers Per Side	Average Weight		Overall Length
ClampStar Part Number	Conductor Range	Inches	mm	Number of Keepers Per Side	Pounds	Kg	Inches	cm
CRU-1140-16-04	447 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	16	13.5	6.1	26.0	66.0
CRU-1386-16-04	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	16	13.5	6.1	26.0	66.0
CRU-1631-16-04	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	16	13.3	6.0	26.0	66.0
CRU-1912-16-04	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	16	13.6	6.2	26.0	66.0

Spline Bits
Part Number	Description
Installation Kit-T45	T45 Torque Spline Bit
Installation Kit-T60	T60 Torque Spline Bit

Catalog

ClampStar® HARDWARE

Installation Kits

Torque Nuts

Spline Bits

Explore

Contact

Corona Shields
CSC-0883-230	Corona shields are generally required for applications above 138 kv. The appropriate shielding is obtained by combining the ClampStar unit number with the highest anticipated system voltage. Example: CSC-1108-230 designates shielding for corona free performance of CRU/CSF/CSR-1108 units installed on a 230 kv system. **Same shield is used for 230 and 345 KV applications
CSC-0883-345 **
CSC-1108-345 **
CSC-XXXX-500

TORQUE NUTS
Part Number	Description	Wrenches
TNHH-500	Zinc housing over HDG Steel nut 1/2-13 thread, 40 ft-lb nominal	Install with 3/4″ socket Remove with 15/16″ deep-well socket
TNHH-500-55	Zinc housing over HDG Steel nut 1/2-13 thread, 55 ft-lb nominal
TNHH-500-SS	Zinc housing over Stainless Steel nut 1/2-13 thread, 40 ft-lb nominal
TNHH-500-BZ	Zinc housing over Stainless Steel nut 1/2-13 thread, 40 ft-lb nominal
TNHH-375	Zinc housing over HDG Steel nut 3/8-16 thread, 22 ft-lb nominal	Install with 9/16″ socket Remove with 3/4″ deep-well socket

INSTALLATION KIT
Part Number	Description
Installation Kit-375	3/8″ eye bolt
Installation Kit-500	1/2″ eye bolt
Installation Kit-EXT-625	5/8″ cable extension for OPGW/OHSW
