ClampStar Part Number	Conductor Diameter Range			Number of Keepers Per Side	Average Weight		Overall Length
ClampStar Part Number	Conductor Range	Inches	mm	Number of Keepers Per Side	Pounds	Kg	Inches	cm
Rigid Frame
CSR-1140S-048	477 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	16	31.9	14.5	92	233.7
CSR-1140FT-048	477 kcmil – 795 kcmil	0.814 – 1.140	20.7 – 29.0	20	36.3	16.5	100	254.0
CSR-1386S-060	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	16	33.8	15.3	104	264.2
CSR-1386H-060	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	20	38.7	17.6	112	284.5
CSR-1386FT-060	605.0 kcmil – 1351.5 kcmil	1.051 – 1.386	26.7 – 35.2	20	38.4	17.4	112	284.5
CSR-1631S-060	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	20	37.9	17.2	112	284.5
CSR-1631H-060	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	26	53	24.04	124	315.0
CSR-1631FT-060	1272 kcmil – 1780 kcmil	1.345 – 1.631	34.2 – 41.4	20	37.9	17.2	112	284.5
CSR-1912S-060	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	20	50	22.7	112	284.5
CSR-1912H-060	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	26	58.0	26.3	124	315.0
CSR-1912FT-060	1351.5 kcmil – 2515 kcmil	1.524 – 1.912	38.7 – 48.6	20	50.3	22.8	112	284.5

ClampStar Part Number	Conductor Diameter Range			Number of Keepers Per Side	Average Weight		Overall Length
ClampStar Part Number	Conductor Range	Inches	mm	Number of Keepers Per Side	Pounds	Kg	Inches	cm
Rigid Frame
CSR-0325L-007-P***	#6 AWG – #2 AWG	0.162 – 0.325	4.1 – 8.3	1	1.7	.8	12.2	31.0
CSR-0325-015	#6 AWG – #2 AWG	0.162 – 0.325	4.1 – 8.3	2	3.5	1.6	26.38	67.0
CSR-0609-024	#2 AWG – 266.8 kcmil	0.316 – 0.609	8.0 – 15.5	2	7.7	3.5	43	109.2
CSR-0642L-024***	2/0 AWG – 266.8 kcmil	0.349 – 0.642	8.9 – 16.3	2	7.7	3.5	43	109.2
CSR-0642-024	2/0 AWG – 266.8 kcmil	0.349 – 0.642	8.9 – 16.3	3	14	6.4	52.8	134.1
CSR-0883L-024***	3/0 AWG – 477 kcmil	0.502 – 0.883	12.8 – 22.4	2	13.1	5.9	43.8	111.3
CSR-0883-036	3/0 AWG – 477 kcmil	0.502 – 0.883	12.8 – 22.4	3	19.1	8.7	65.4	166.1
CSR-1108L-024***	336.4 kcmil – 795 kcmil	0.684 – 1.108	17.4 – 28.1	2	14.4	6.5	43.8	111.3
CSR-1108-040	336.4 kcmil – 795 kcmil	0.684 – 1.108	17.4 – 28.1	4	27	12.2	78.8	200.2

TORQUE NUTS
Part Number	Description	Wrenches
TNHH-500	Zinc housing over HDG Steel nut 1/2-13 thread, 40 ft-lb nominal	Install with 3/4″ socket Remove with 15/16″ deep-well socket
TNHH-500-55	Zinc housing over HDG Steel nut 1/2-13 thread, 55 ft-lb nominal
TNHH-500-SS	Zinc housing over Stainless Steel nut 1/2-13 thread, 40 ft-lb nominal
TNHH-500-BZ	Zinc housing over Stainless Steel nut 1/2-13 thread, 40 ft-lb nominal
TNHH-375	Zinc housing over HDG Steel nut 3/8-16 thread, 22 ft-lb nominal	Install with 9/16″ socket Remove with 3/4″ deep-well socket

Spline Bits
Part Number	Description
Installation Kit-T45	T45 Torque Spline Bit
Installation Kit-T60	T60 Torque Spline Bit

INSTALLATION KIT
Part Number	Description
Installation Kit-375	3/8″ eye bolt
Installation Kit-500	1/2″ eye bolt
Installation Kit-EXT-625	5/8″ cable extension for OPGW/OHSW

Explore

Contact

Corona Shields
CSC-0883-230	Corona shields are generally required for applications above 138 kv. The appropriate shielding is obtained by combining the ClampStar unit number with the highest anticipated system voltage. Example: CSC-1108-230 designates shielding for corona free performance of CRU/CSF/CSR-1108 units installed on a 230 kv system. **Same shield is used for 230 and 345 KV applications
CSC-0883-345 **
CSC-1108-345 **
CSC-XXXX-500
